My FANUC Tool

FANUC engineering software for LS editing, backup exports, layout conversion, and 3D review.

My FANUC Tool combines dashboard access, offline FANUC extraction, LS program editing and compare, AI-assisted LS writing, TRSF recipe generation, Excel round-tripping, and DXF, PDF, GLB, and STL layout workflows.

Download software See pricing

Multi-robot extraction and LS workspaces

AI-assisted LS writing and TRSF recipes

DXF, PDF, GLB, STL, and Excel outputs

My FANUC Tool

Edit, compare, and clean FANUC LS files.

Excel

Export controller and backup data into readable tables.

DXF / GLB

Generate layout documentation and browser-ready review files.

LS workflows

Edit and parse with less cleanup

Work directly with FANUC LS files when you need cleaner engineering handover and review.

Exports

Excel, DXF, PDF, and GLB

Turn robot backups and layout data into outputs the rest of the team can actually use.

Evaluation

14 days to validate

Test the workflow before you commit to a monthly, annual, or enterprise plan.

Pricing

EUR 25 monthly or EUR 275 yearly

Clear per-PC licensing with enterprise options when your rollout needs more flexibility.

What It Does

One app for FANUC extraction, LS work, and layout output.

My FANUC Tool combines multi-robot extraction, LS editing, AI-assisted program writing, TRSF generation, Excel round-tripping, and 2D and 3D layout output in one workflow.

Download software

Dashboard

Launch the workflow from one place.

The dashboard gives quick access to files, templates, manuals, and references instead of sending engineers through scattered folders.

Lets you copy out the FANUC payload workbook template.
Opens the manual PDF and external FANUC alarm reference site.

Extraction

Build multi-robot extraction projects.

Extraction is the main FANUC data workspace. You can create a project, add multiple robots, and move work between full projects and single-robot bundles.

Save and load full projects as .mftproj.
Save and load single-robot extraction bundles as .b64.
Generate starter extract files and read FANUC export text/comment folders.

Extraction Data

Edit the FANUC data teams actually use.

The extraction workspace builds editable tables for audits, cleanup, handover, and deployment while keeping a lot of raw numeric robot data intentionally read-only.

Registers, PRs, user frames, user tools, payload, space check, REF positions, flags, macros, robot info, and system variables.
Digital, group, and robot inputs and outputs with practical comment editing in the UI.
Excel export/import, KAREL support/comment exports, empty default configs, equipment-position CSV import, and per-robot GLB model attach/view/export.

LS Programs

Import, compare, edit, and export LS programs.

The LS workspace has its own project and robot structure so program work stays organized while still matching the Extraction data for the same robots.

Import .LS programs, create blanks, copy programs, and delete programs.
Compare two to three programs side by side, preview full code, and change comments.
Export program data to Excel for editing and export selected programs back to .LS.

Write Program AI

Generate FANUC LS code with project context.

Write Program AI loads robot datasets from Extraction, lets you browse tables, insert live references into a prompt, and generate LS code with the actual project data in view.

Browse PRs, registers, DI/DO, UF/UT, payload, macros, and related tables.
Send instructions to OpenAI and keep generation history.
Import the generated FANUC program straight into the LS workspace.

Layout + 3D

Create DXF, PDF, GLB, and STL-based outputs.

The layout side of the app covers both 2D documentation and 3D review, including RoboGuide-style placement workflows and STL utility pipelines.

Floor Plan converts placement CSV plus STL files into 2D DXF, then DXF to PDF with page size, scale, title block, author, and optional grid settings.
Create 3D Plan combines STL files plus placement CSV into a single .glb scene.
STL functions include decimation, STL combining with CSV placement, and STL-to-interactive-3D-PDF output.

FANUC Strengths

Built for real FANUC engineering work.

Organize backups, edit LS files, clean comments, and hand over data in formats the rest of the team can use.

Core strengths

Strong offline extraction and practical editing.

The app is designed around real FANUC configuration work instead of just file conversion.

Strong support for offline FANUC data extraction and organization.
Practical IO and comment editing for robot configuration data.
Excel round-tripping for extracted robot data as part of review and cleanup.
KAREL export helpers for comment and data deployment workflows.

Program workflows

LS, AI, and TRSF workflows stay connected.

Program generation and program editing stay tied back to the extracted FANUC project context.

LS program import, viewing, comparison, comment editing, and LS export.
AI-assisted FANUC LS generation with project context from the extraction dataset.
TRSF recipe program generation from extracted PR data.
Excel round-tripping for both extracted robot data and LS programs.

Tool Suite

Choose the exact FANUC workflow you need.

Each page is built around a real task so search traffic can land on the right solution, understand the output, and move naturally into a download or a license.

Download software

LS editing

FANUC LS Tools

Edit, compare, clean, and export FANUC LS files with a workflow that is easier to review and safer to hand over.

Open LS Tools

LS parsing

FANUC LS Parser

Parse FANUC LS files into readable structure for registers, labels, frames, and program details.

Open LS Parser

Backup exports

Backup to Excel

Export FANUC backup data into workbook-ready tables for registers, frames, tools, payloads, and labels.

Open Backup to Excel

Layout documentation

RoboGuide STL to DXF

Convert RoboGuide STL exports into DXF and PDF layout packs for documentation and review.

Open STL to DXF

3D review

STL to GLB

Merge STL files into a single GLB scene for browser-based layout review and cross-team sharing.

Open STL to GLB

Transforms

TRSF Generator

Generate repeatable FANUC TRSF pairs from guided tables using PR, UTool, UFrame, and controller options.

Open TRSF Generator

Pricing

Choose monthly, annual, or enterprise licensing.

Start with the built-in evaluation, then buy the license that fits your rollout.

Full pricing page

Monthly

EUR 25 / month

Per PC. Good for validation, small teams, or active short-term rollout.

Hardware-locked license
Full tool access
Email support
14-day evaluation first

Buy monthly

Annual

EUR 275 / year

Per PC. Better value for teams using the software as part of their regular engineering workflow.

Hardware-locked license
Full tool access
Email support
Lower yearly cost

Buy annual

Enterprise

Site and volume options

For multi-seat teams, broader deployment, offline activation, or rollout planning support.

Volume discussions
Offline activation options
Priority support conversations
Rollout planning

Talk to PathLogic

Prices exclude VAT. EU VAT is collected where applicable via Stripe.

Ready to test My FANUC Tool on a real job?

Download software, review pricing, or send PathLogic the workflow you want to validate first.
